Radium BX 700W

SVXRBX700
SVXRBX700
SVXRBX700
SVXRBX700

Radium BX 700W

SVXRBX700
  • Universal AC input 100V - 240V
  • 80 Plus Bronze certified
  • Over 85% efficiency under typical load conditions
  • 6 protection systems
  • 80plus bronze
⚡

Active PFC

Active power factor correction with a typical rating above 0.99 for improved stability and energy efficiency.

🏅

80 Plus Bronze Efficiency

Over 85% efficiency at typical loads, reducing power consumption and heat output.

🛡️

Comprehensive Protections

Includes OVP, SCP, OPP, OTR, SIP, and UVP to safeguard your system against electrical issues.

🌀

Smart Cooling

120 mm fan with automatic speed control balances silence with cooling performance.

Technical Specifications

Form Factor ATX
Power Output 700 W
Input Voltage 100 – 240 V
Input Frequency 47 – 63 Hz
PFC Active PFC (>0.99 typical)
Efficiency Over 85% at typical load 80 Plus Bronze
Protection Systems OVP, SCP, OPP, OTR, SIP, UVP
Cooling 120 mm fan with smart speed control
Connectors 1 × M/B (20+4 pin)
1 × CPU (4+4 pin)
6 × SATA
3 × Peripheral (Molex 4 pin)
4 × PCI‑E (6+2 pin)
1 × Floppy (FDD)
Dimensions (L) 185 × (H) 85 × (W) 140 mm
Weight ≈ 2.43 kg
Finish / Color Black chassis with orange accents; metal mesh grille
